Specification Product Digital analyzer monitoring Model SUP-DC2000 Dimension 100mm*100mm*150mm Range pH: (0-14)pH ORP: (-2000-2000) mV DO: (0-40) mg/L TDS: (0-600) mS/cm Tur
Range: pH: (0～14)pH
ORP:(-2000～2000)mV
DO:(0～40)mg/L
TDS: (0～600)mS/cm
Turbidity: (0～4000)NTU
Suspended solids: (0～120000)mg/L
Output signal: 4~20mA; Relay; RS485
Power supply: AC：(100～240)VAC; DC：24VDC(Optional)
Specification
| Product | Digital analyzer monitoring |
| Model | SUP-DC2000 |
| Dimension | 100mm*100mm*150mm |
| Range | pH: (0-14)pH ORP: (-2000-2000) mV DO: (0-40) mg/L TDS: (0-600) mS/cm Turbidity: (0-4000) NTU Suspended solids: (0-120000) mg/L |
| Relative humidity | (10-85)% |
| Temperature range | (0-60)℃ |
| Communication | RS485, Modbus-RTU |
| Signal output | 4-20mA, maximum loop 500Ω, 0.2%FS |
| Power supply | AC: (100-240)VAC DC: 24VDC(Optional) |
| Relay output | 250VAC, 3A |
